John Deere 313D
| Daily | Weekly | Monthly | |
| Reg | $220 | $960 | $2,600 |
| Corp | $210 | $890 | $2,430 |
We honor the lowest rate on ALL rentas
John Deere 313D highlights
| Machine Dimensions | ||||||
| A | Length without Bucket | 8 ft. 0 in. (2.44 m) | ||||
| B | Length with Bucket (60-in. foundry) | 10 ft. 4 in. (3.14 m) | ||||
| C | Width without Bucket | 4 ft. 11 in. (1.50 m) | ||||
| Equipped with Optional 7 x 15 Tires | 4 ft. 8 in. (1.47 m) | |||||
| D | Height to Top of ROPS | 6 ft. 5 in. (1.96 m) | ||||
| E | Height to Hinge Pin | 9 ft. 1 in. (2.77 m) | ||||
| F | Dump Height | 7 ft. 0 in. (2.13 m) | ||||
| G | Dump Reach | |||||
| Foundry Bucket | 17.4 in. (442 mm) | |||||
| Construction Bucket | 23 in. (0.58 m) | |||||
| H | Wheelbase | 3 ft. 2 in. (0.95 m) | ||||
| I | Ground Clearance | 7.6 in. (193 mm) | ||||
| J | Angle of Departure | 26 deg. | ||||
| K | Front Turn Radius | 6 ft. 2 in. (1.89 m) | ||||
| L | Dump Angle (full lift height) | 40 deg. | ||||
| M | Bucket Rollback (ground level) | 30 deg. | ||||
| Maximum Reach with Arms Parallel to Ground | 3 ft. 11 in. (1196 mm) | |||||
| Tipping Load | 2,525 lb. (1146 kg) | |||||
| SAE Rated Operating Capacity | 1,260 lb. (572 kg) | |||||
| With Counterweight | 1,400 lb. (636 kg) | |||||
| Boom Breakout | 2,800 lb. (1271 kg) | |||||
| Bucket Breakout Force | ||||||
| Foundry Bucket | 3,300 lb. (1498 kg) | |||||
| Construction Bucket | 2,178 lb. (989 kg) | |||||
313D key benefits
Demolition ready excavator rentals:
Power
Compact:
Visibility:
Low operation noise:
- Backfill trenches
- Dig trenches
- Prepare grounds for landscaping
- Snow removal
- Remove debris from construction sites
- Fence pole installation
- Sod removal
- Clear land and load rubbish bins
- Plant trees
- Remove stumps
- Load pickup trucks, hoppers and spreaders
- Grade and level driveways
- Load sand and gravel
- Brush Cutting
